Neutrik NBNC75BFG7X BNC Plug Image 360

  • NBNC75BFG7X
    NBNC75BFG7X
  • NBNC75BFG7X drawing
    NBNC75BFG7X drawing
Neutrik NBNC75BFG7X BNC Plug Image 360
PN - BA-65-5110
£5.75(ex vat) / Each
Qty Price
1-4£5.75 (ex vat)
5-9£3.34 (ex vat)
10+£3.14 (ex vat)

The rearTWIST UHD BNC connectors are specifically designed for high resolution video signal transmissions. Due to the unique insulator and contact pin design, the connectors feature low return loss values for 4K and 8K signals.

Optimised Return Loss
Due to optimised insulator design and reduced crimp diameter from center pin the Neutrik rearTWIST UHD BNC connector achieves increased headroom compared to conventional BNC connectors and offers additional return loss reserve for potential impedance deviations resulting from cable bending, incorrect connector assembly or faulty connection interfaces without signal interruption.

Key Benefits:
• Optimised contact pin and insulator design for UHD-data transmissions
• Proven rearTWIST technology
• Swiss antraloy plating
• Fully compatible with conventional BNC chassis connectors
• Improved return loss values at high frequencies

Connection type: BNC 75 Ω
Gender: male

Electrical
Contact resistance: ≤ 3 mΩ (inner)
Contact resistance: ≤ 2 mΩ (outer)
Dielectric strength: 1.5 kVdc
Impedance: 75 Ω
Insulation resistance: > 5 GΩ
Rated voltage: <50 V
VSWR: ≤1.06 / >30 dB up to 6 GHz
            ≤1.13 / >24 dB up to 12 GHz
            ≤1.22 / >20 dB up to 18 GHz

Environmental
Temperature range: -30 °C to +85 °C
Contact crimpability: Complies with IEC 60803 and IEC 60352-2

 Mechanical
Cable O.D.: 4.7 mm
Cable retention: > 30 N (Center)
Crimp size: 5.0 Hex crimp (shield) 1.07 crimp (pin)
Insertion force: < 25 N
Lifetime: > 1000 mating cycles
Locking device: Bayonett
Cable anchoring: Jacket crimping
Material Contacts: Brass: (CuZn35Pb2), 0.2 µm AuCo (center contact)
Insert: PP
Shell: Brass (CuZn39Pb3)
Shell plating: Antraloy
